Unequal IBeam  Geometric Properties
Geometric Property Calculator



The above unequal ibeam property calculator is based on the provided equations and does not account for all mathematical limitations. The calculator has been provided with educational purposes in mind and should be used accordingly. Unit conversion
Notation and Units
Metric and Imperial Units
The above formulas may be used with both imperial and metric units. As with all calculations care must be taken to keep consistent units throughout. Examples of units which are typically adopted are outlined below:
Notation
 A = Geometric Area, in^{2} or mm^{2}
 C = Distance to Centroid, in or mm
 I = Second moment of area, in^{4} or mm^{4}
 J_{i} = Polar Moment of Inertia, in^{4} or mm^{4}
 J = Torsional Constant, in^{4} or mm^{4}
 K = Radius of Gyration, in or mm
 P = Perimeter of shape, in or mm
 Z = Elastic Section Modulus, in^{3} or mm^{3}
Online Unequal IBeam Property Calculator
Using the structural engineering calculator located at the top of the page (simply click on the the "show/hide calculator" button) the following properties can be calculated:
 Calculate the Area of a Unequal IBeam
 Calculate the Perimeter of a Unequal IBeam
 Calculate the Centroid of a Unequal IBeam
 Calculate the Second Moment of Area (or moment of inertia) of a Unequal IBeam
 Calculate the Polar Moment of Inertia of a Unequal IBeam
 Calculate the Radius of Gyration of a Unequal IBeam
 Calculate the Elastic Section Modulus of a Unequal IBeam
 Calculate the Plastic Section Modulus of a Unequal IBeam
